Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
This product is currently out of stock and unavailable. SKU: Concrete Block Molds QT12-15 Cement Bricks-35644772 Category: Stationary block machine Description Additional information Description Products Description QT12-15 CEMENT BLOCK MAKING MACHINEConcrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production LineQT12-15 automatic block making machine is a special-purpose equipment for […]
Automation
Fully Automatic
Vibration
Air-bag System
Lead Time
15-25 Working Days
Warranty
12 Months
Product Details
Products Description
QT12-15 CEMENT BLOCK MAKING MACHINE
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
QT12-15 automatic block making machine is a special-purpose equipment for making building block making machine. The material of this machine can be fly ash. slag. gangue or the other industrial wastes. river sand. gravel. cement etc. Makes different sizes of hollow blocks. porous blocks. curbstone. pavement blocks. grass blocks. slope-protecting blocks. ring-tree blocks etc. If add color machine. it can make paving blocks.
Composition:Six major components: Pallet feeder. molding machine. storage hopper. block conveyor. hydraulic station. electrical PLC cabinet.
STRUCTURE:
The simple production line:
PL1200 batching machine. JS500 or JS750 mixer. 8m conveyor belt and stacker.
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
QT12-15 BLOCK MAKING MACHINE
Mold operation and maintenance:(1)When installing or changing new mold and old mold.it must avoid crush.installing politely.pay attention to protect the mold.(2)Checking the mold dimension and the condition of the welding place during the operation.repairing on time when the bead crack apeared;revising the aggregate size when fast attrition appeared. if the mold excessive abraded and affect the quality of the product. it need to change the new mold.(3)Adjust the gap carefully.including the pressure head and mold core.pressure head and distributing box.mold box and the distributing plane of motion.mold box and pallet EqualInterval.Relative motion shall not be interfered.friction touch.
(4)When cleaning the mold.using the air compressor and soft tool to clear away concrete residue. it is prohibited to knock and Skid scraping the mold.
(5) The replaced mold.wash clearly.Oil antirust.Shall place the drying.flatwise.avoiding Gravity deformation
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
Main technical parameters
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line | ||
Overall Dimension | 9350 x 2520 x 2950mm | |
Total Mass | 12000 kgs | |
Overall Power | 52kw | |
Pallet Size | 1300x900mm | |
Molding Cycle | 15-25s | |
Vibration Form | Platform Vibration | |
common blocks samples
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
BLOCK MOLDS
The mould includes hollow block mould. standard brick mold and pavement brick. road kerb. slope protection brick. planting grass brick mould. etc.
We have different kind of mold for paver brick.curbstone .slop protection brick and planting leather brick etc.the customer can choose the mold according to his requirement.we can also make the mold by the customer’s drawings.
Concrete Block Molds QT12-15 Cement Bricks Making Machine Lowest Price Brick Machine Making Automatic Production Line
Packaging And delivery
Company Profile
customer working site
